Bulkhead | ||
INDOOR MODEL | BRE-026CS | |
Moisture Removal (L/hr) | N/A | |
IP Rating | IPX0 | |
Airflow Range |
Boost | N/A |
High | 139 | |
Medium | 94 | |
Low | 64 | |
Indoor Dimensions |
Depth | 506 |
Height | 200 | |
Width | 700 | |
Full Load Amps (AS/NZS3823.1.2)- Indoor Unit | 1.1 | |
Nominal Weight | 18.0 | |
Indoor Sound Pressure Level (dBA)
(Low / Med / High) |
27.5 / 34.5 / 40 |
|
Indoor Unit Connections | Liquid Pipe – mm (inch) | 6.35 (1/4) |
Gas Pipe – mm (inch) | 9.52 (3/8) | |
Field Pipe Size | Liquid Pipe – mm (inch) | 6.35 (1/4) |
Gas Pipe – mm (inch) | 9.52 (3/8) |
