DAIKIN FCA125C-CC2V 12.5kW Standard Inverter Reverse Cycle Cassette Air Conditioner System | 1 Phase

DAIKIN FCA125C-CC2V 12.5kW Standard Inverter Reverse Cycle Cassette Air Conditioner System | 1 Phase

SKU: FCA125C-CC2V / FCA125CVMA / RZAC125C2V1 / BYCQ125EAF / BRC1H63W

12.5 kW Cooling
14.0 kW Heating

DAIKIN FCA125C-CC2V 12.5kW Standard Inverter Reverse Cycle Cassette System | 1 Phase
Includes Indoor – FCA125CVMA | Outdoor – RZAC125C2V1
Fascia – BYCQ125EAF
Wired Controller – BRC1H63W

Or own it from $201.15 weekly for 6 months*

Or pay in slices, no interest ever

Or own it from $201.15 weekly for 6 months*

Or pay in slices, no interest ever

Model Name		Indoor unit		FCA125CVMA
		Outdoor unit		RZAC125C2V1
Power supply				1 Phase, 220-240V, 50Hz
Cooling capacity1,3 Rated (Min. – Max.)			kW	12.5 (4.0-14.0)
Heating capacity2,3 Rated (Min. – Max.)			kW	14.0 (4.1-16.0)
Power consumption		Cooling 1	kW	3.53
		Heating 2	kW	3.63
EER		Cooling	kW/kW	3.54
COP		Heating	kW/kW	3.86
AEER		Cooling		3.49
ACOP		Heating		3.8
TCSPF (Cooling) Commercial / Residential		Hot		5.30 / 4.91
		Average		5.38 / 4.46
		Cold		5.74 / 4.60
HSPF (Heating) Commercial / Residential		Hot		4.66 / 4.66
		Average		4.40 / 4.22
		Cold		4.03 / 3.80
Indoor unit	Colour	Unit		———
		Decoration panel		Fresh White
	Airflow rate (H / HM / M / ML / L)		/s	608 / 558 / 500 / 442 / 383
			m3/min	36.5 / 33.5 / 30.0 / 26.5 / 23.0
	Sound pressure level4 (H / HM / M / ML / L)		dB(A)	46.0 / 43.5 / 41.0 / 38.5 / 36.0
	Dimensions (HXWXD)	Unit	mm	298X840X840
		Decoration panel	mm	50X950X950
	Machine weight	Unit	kg	26
		Decoration panel	kg	5.5
	Certified operation range	Cooling	°CWB	14 to 25
		Heating	°CDB	15 to 27
Outdoor	Colour			Ivory White
unit	Compressor	Type		Hermetically sealed swing type
		Motor output	kW	3.3
	Refrigerant charge (R-32)		kg	2.90 (Charged for 30 m)
	Sound pressure level 4	Cooling / Heating	dB(A)	53 / 56
		Night quiet mode	dB(A)	49
	Sound power level		dB(A)	———–
	Dimensions (HXWXD)		mm	990X940X320
	Machine weight		kg	78
	Certified operation range	Cooling	°CDB	-5 to 46
		Heating	°CWB	-15 to 15.5
Piping connections	Liquid (Flare)		mm	o/ 9.5
	Gas (Flare)		mm	o/ 15.9
	Drain	Indoor unit	mm	VP25 (I.D. o/ 25XO.D. o/ 32)
		Outdoor unit 5	mm	Connectable hose I.D. o/ 25
Max. interunit piping length			m	50 (Equivalent length 70)
Max. installation height difference			m	30
Heat insulation				Both liquid and gas piping

Available in Reverse Cycle (Heating & Cooling)
Capacities Premium Inverter: 5.0kW-14.0kW
Refrigerant: R32

The SkyAir Round Flow Cassette with Streamer utilises 360 degree airflow distribution to ensure even temperatures throughout the space, this provides a comfortable environment for building occupants all year round while also remaining discrete. Additionally, its built-in Streamer technology facilitates powerful oxidative decomposition of pollutants present on the cassette’s filter for enhanced indoor air quality.

The Round Flow Cassette with Streamer are paired with our Premium Inverter (RZAV) condensers, offering building owners substantial operating efficiencies to help minimise operating costs. R22 retrofit capability is also available on these condensers allowing for a simplified cost effective replacement solution.

DAIKIN FCA125C-CC2V 12.5kW Standard Inverter Reverse Cycle Cassette Air Conditioner System | 1 Phase – Brochure

Daikin Round Flow Cassette

Available in : Reverse Cycle (Heating & Cooling)
Capacities : Premium Inverter: 5.0kW-14.0kW, Inverter: 7.1kW-14.0kW
Refrigerant : R32

The SkyAir Round Flow Cassette utilises 360 degree airflow distribution to ensure even temperatures throughout the space, this provides a comfortable environment for building occupants all year round while also remaining discrete.

The Daikin Round Flow Cassette can be either paired with our Premium Inverter (RZAV) or Inverter (RZAC) condensers. The former offering building owners substantial operating efficiencies to help minimise operating costs. R22 retrofit capability is available for both condenser types allowing for a simplified cost effective replacement solution.

All Daikin air conditioners exceed MEPS requirements, in line with Daikin’s commitment to providing energy efficient, quiet, simple to use and reliable air conditioning solutions.

SkyAir

Designed for use in shops, restaurants and small offices, Daikin Sky Air provides a comfortable environment for building occupants all year round and offers building owners substantial operating efficiencies to help minimise operating costs.
