DAIKIN FDYA100A9-C2V 10.0 kW Premium Inverter Ducted Air Conditioner System | 1 Phase

SKU: FDYA100A9-C2V / FDYA100AV19 / RZAS100C2V1 / BRC1E63

10.0 kW Cooling | 12.0 kW Heating
DAIKIN FDYA100A9-C2V 10.0kW Premium Inverter Ducted Air Conditioner System | 1 Phase
Includes Indoor  FDYA100AV19 | Outdoor RZAS100C2V1
BRC1E63 – Standard Nav Ease Controller




> > > > > Compare
INDOOR UNIT FDYA100AV19
OUTDOOR RZAS100C2V1
Rated Capacity
Cool (kW) 10
Heat (kW) 12.5
Capacity Range
Cool (kW) 5.0-11.2
Heat (kW) 5.1-14.0
Power Input (Rated)
Cool (kW) 2.61
Heat (kW) 3.13
E.E.R/C.O.P C/H 3.83/3.99
TCSPF (Residential) Hot/Average/Cold 4.69/4.22/4.25
HSPF (Residential) Hot/Average/Cold 4.43/4.07/3.62
Airflow Rate (Nominal/Max) l/s 680/800
Indoor Sound Level (H) @ 1.5m dBA (C/H) 42.3/45.0
Piping Length m 75
Indoor Fan Speeds H/M/L
Dimensions (HxWxD)
Indoor (mm) 300x1210x900
Outdoor (mm) 1430x940x320
Weight
Indoor (kg) 46
Outdoor (kg) 93
Power Supply V/Hz 1 Phase, 220-240V, 50Hz
Compressor Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Refrigerant R32
Pipe Sizes
Liquid (mm) 9.5 (Flared)
Gas (mm) 15.9 (Flared)
Drain (mm) ID 25 / OD 32
Supply Air Opening mm (HxW, Flange) 185×852
Return Air Opening mm 2×350 (Oval)
Outdoor Operating Range
Cool (ºCDB) -5 to 50
Heat (ºCWB) -15 to 16
EPA Sound Power Level dBA 70
Outdoor Sound Level (H) @ 1m Pressure dBA (C/H) 51/53

Features and benefits

Energy efficiency

Inverter operation – An inverter system works like the accelerator of a car, gently increasing or decreasing power to steadily maintain your optimum temperature without fluctuations. That means uninterrupted comfort and significant savings on running costs. Daikin Premium Inverters can also reach your desired temperature faster than conventional air conditioners.

Automatic mode changeover – Automatically selects heating or cooling modes to suit thermostat settings and prevailing room temperature.

Predicted Mean Vote (PMV) Control – Measures indoor and outdoor temperatures to calculate the ideal room temperature, gently adjusting it for the optimum balance between efficiency and comfort.

Temperature limit operations –Lets you pre-define temperature range for cooling or heating, to reduce energy consumption.

Home Leave –  Ideal for cold climates, Home Leave turns your air conditioner on automatically when room temperatures drop below 10 ̊C, keeping your home at or above 10 ̊C so it never gets really cold.

Automatic functions – Auto restart after power failure. The air conditioner memorises the settings for mode, airflow, temperature etc. and automatically returns to them when power is restored after a power failure.

Self diagnosis with digital display – Malfunction codes are displayed on your control panel for fast, easy fault diagnosis and maintenance.

Anti-corrosion coating – An anti-corrosion coating on outdoor heat exchangers gives greater resistance to salt damage and atmospheric corrosion.

Compact design – The compact design of Daikin ducted indoor units allows them to be installed in confined areas, and they can also be dismantled for easier installation in tight roof spaces.

Comfort control

Night Quiet Mode – Outdoor unit noise is automatically reduced by 3dB when outdoor temperatures fall more than 6 ̊C from the day’s maximum (set during installation).

Program Dry Mode – In this mode, priority is given to reducing the level of humidity in the room rather than room temperature.

Intelligent Defrost – During heating operation in low ambient temperature conditions, frost can form on the outdoor unit heat exchanger which can reduce your air conditioner’s performance. Daikin’s Intelligent Defrost system constantly monitors a range of system parameters and temperatures to determine the optimum time to commence a defrost operation for maximum performance in cold conditions.

Hot start – Prior to heating, the indoor unit warms to a pre-set temperature before the fan switches on, ensuring only warm air is discharged, eliminating cold drafts.

Quick cool/heat – Powerful Mode – This feature temporarily increases power to more rapidly reach your desired room temperature, before automatically returning to normal operation.

Timer control – 24 hour on/off timer – This timer can be pre-set to start and stop at any time within a 24 hour period.

Night Set Mode – A timer off circuit gradually adjusts pre-set cooling and heating levels, preventing sudden temperature changes during the night and improving economy.

Seven day time clock – This allows you to program your air conditioner to turn on or off at set times for every day of the week.

5 Year Warranty

DAIKIN FDYA100A9-C2V 10.0 kW Premium Inverter Ducted Air Conditioner System | 1 Phase – Brochure

Description

10.0kW Cooling
12.5kW Heating

Daikin Controller

We have a range of controllers available to control your DAIKIN ducted air conditioning system to suit your lifestyle needs.

NAV EASE CONTROLLER

Daikin-BRC1E63-zone-controller

NAV EASE MODEL NO: BRC1E63

FEATURES:
1. Clear, backlit display with easy-to-read text.
2. Weekly schedule timer, to program on and off times.
3. Home Leave function can turn your air conditioner on automatically when room temperatures drop below 10 ̊C.
4. Quick Cool / Heat mode, which temporarily increases air conditioning power to more rapidly reach your desired operating temperature, before automatically returning to normal operation.
5. Set Temperature Mode Changeover, automatically switches from a cooling to heating cycle, or a heating to cooling cycle at pre-set points.
6. Temperature Limit, to predefine a temperature range for cooling or heating cycles, helping you reduce your energy consumption.

ZONE CONTROLLER

(On/Off Control Only)

daikin-BRC230Z4B-BRC230Z8B-BRC24Z4B-BRC24Z8B-zone-controller

Zone Controller Models:
BRC230Z4B9 – Up to 4 Zones (230-240v)
BRC230Z8B9 – Up to 8 Zones (230-240v)
BRC24Z4B9   – Up to 4 Zones (24v)
BRC24Z8B9   – Up to 8 Zones (24v)

FEATURES

1. Backlit display with easy-to-read text.
2. Three different timer and time clock operations for precise, programmable control for your home.
3. Countdown On-Off timer, programmable in 1 hour increments for up to 12 hours.
4. A simple 7-day Time Clock, to program the controller to turn the system on or off at set times any day of the week. Two different on and off programs can be set for each day of the week.
5. An advanced 7-day Time Clock extends the functionality of the Simple 7-day Time Clock with advanced features such as Zone Control and Temperature Sensor Selection, for the ultimate in-home comfort.
6. Airside Control when connected with Premium Inverter (71-250 Class) & Inverter (50-160 Class) Ducted models.



Notes:
1. Nav Ease & Zone Controller is only compatible with FDYA(N) & FBA models, FDXS models come standard with a wireless remote controller
2. Airside Control function regulates the fan RPM between 60% to 100% of the indoor unit’s rated airflow
3. Airbase is not compatible with Slave Zone Controller
