Indoor unit | ASTH24KMTD |
Outdoor unit | AOTH24KMTD |
Operation Type | Reverse Cycle |
Power Source V/Ph/Hz | 230 / 1 / 50 |
Cooling Capacity kW (Rated (Min – Max)) | 7.10 (1.1 – 8.3) |
Heating Capacity kW (Rated (Min – Max)) | 8.00 (1.1 – 10.1) |
Input Power Cooling kW (Rated (Min – Max)) | 2.08 (0.24 – 3.15) |
Input Power Heating kW (Rated (Min – Max)) | 1.91 (0.14 – 3.17) |
EER Cooling kW/kW | 3.41 |
COP Heating kW/kW | 4.19 |
Star Rating Cooling (0-10) (Hot / Average / Cold) | 3.5 / 3.5 / 3.5 |
Star Rating Heating (0-10) (Hot / Average / Cold) | 3 / 2.5 / 2 |
Total Cooling Seasonal Performance Factor Residential kW (Hot / Average / Cold) | 5.344 / 5.094 / 5.481 |
Heating Seasonal Performance Factor Residential kW (Hot / Average / Cold) | 4.819 / 4.265 / 3.586 |
Total Cooling Seasonal Performance Factor Commercial kW (Hot / Average / Cold) | 5.873 / 6.231 / 6.897 |
Heating Seasonal Performance Factor Commercial kW (Hot / Average / Cold) | 4.817 / 4.474 / 3.909 |
Running Current amps (Cooling / Heating) | 9.3 / 8.7 |
Moisture Removal l/hr | 2.7 |
Indoor Sound Pressure Cooling dBA (High / Quiet) | 49 / 29 |
Indoor Sound Pressure Heating dBA (High / Quiet) | 49 / 29 |
Outdoor Sound Pressure dBA (Cooling / Heating) | 54 / 53 |
Outdoor Sound Power dBA | 66 |
Air Circulation (Indoor – High Fan) Cooling l/sec | 325 |
Air Circulation (Indoor – High Fan) Heating l/sec | 331 |
Indoor Unit Dimensions mm (Height x Width x Depth) | 280 x 980 x 240 |
Indoor Unit Weight kg | 12.50 |
Outdoor Unit Dimensions mm (Height x Width x Depth) | 716 x 820 x 315 |
Outdoor Unit Weight kg | 42.00 |
Piping Connects mm Ø (Liquid / Gas) | 6.35 / 12.7 |
Pipe Length m (Max (Precharged)) | 30 (15) |
Max Height Difference m | 25 |
Operation Range Cooling °CDB (Min to Max) | -10 to 50 |
Operation Range Heating °CDB (Min to Max) | -15 to 24 |
Refrigerant Type | R32 |
FUJITSU SET-ASTH24KMTD 7.1kW Lifestyle Inverter Split System Air Conditioner
7.1kW Cooling | 8.0kW Heating
Fujitsu Lifestyle Range SET-ASTH24KMTD Reverse Cycle Inverter Split System Air Conditioner
Includes Indoor ASTH24KMTD | Outdoor AOTH24KMTD
Wireless Remote
Comfort Functions
- 10º C Heat Operation The room temperature can be set to go no lower than 10°C, ensuring that the room does not get too cold when not occupied.
- Up/Down Swing Louvre The up/down louvre automatically swings up and down. Right/Left Swing Louvre¹ The right/left louvre automatically swings in either direction.
- Double Swing Automatic¹ Complex swing action of the louvres enables them to swing automatically in both horizontal and vertical directions.
- Automatic Louvre The position of the louvres is set automatically to match the operating mode. It is also possible to adjust the louvres using the remote control.
- Auto Shut Louvre The auto shut louvres close or open automatically when the unit stops or starts.
- Automatic Air Flow Adjustment When auto mode is selected for the fan, the micro-processor adjusts the airflow to follow changes in room temperature.
- Auto Restart Should there be temporary loss of power, the unit will automatically restart itself in the same operating mode, once the power is restored.
- Auto-Changeover The unit automatically switches between heating and cooling modes based on the temperature setting and room temperature.
- Powerful Mode Powerful mode will operate the indoor unit fan and outdoor unit compressor at maximum operation to quickly make the room conditioned and comfortable
Convenience Functions
- Sleep Timer The micro-processor gradually changes the room temperature, allowing you to sleep comfortably at night.
- Program Timer This timer allows selection of one of four options. ON, OFF, ON ––> OFF, or OFF ––> ON.
- Filter Sign Set the interval frequency to be reminded to clean the air filter on your unit.
- On-Off Timer ON-OFF timer can be set to operate once every 24 hours.
- Weekly Timer Different ON-OFF timers can be set for up to 7 days.
- Auto-Off Timer² The unit automatically stops operating when a fixed time has elapsed.
Description
7.1 kW Cooling
8.0 kW Heating
Human Sensor Inbuilt | Super Quiet Mode
