Model |
GWH28ATEXF-K6DNA1A/I |
|||||
GWH28ATEXF-K6DNA1A/O |
||||||
Performance |
||||||
Cooling Capacity (Range) |
kW |
8.2 (3.3~9.67) |
||||
Heating Capacity (Range) |
kW |
9.0 (3.0~10.14) |
||||
Cooling Power Input |
kW |
2.44 |
||||
Heating Power Input |
kW |
2.65 |
||||
Cooling AEER |
W/W |
3.28 |
||||
Heating ACOP |
W/W |
3.39 |
||||
Heating Capacity H2 |
kW |
6.86 |
||||
Power Input Heating H2 |
kW |
2.62 |
||||
SERL Star Label |
Cool |
4/3.5/3.5 |
||||
Hot/Ave/Cold |
Heat |
3.5/2.5/2 |
||||
Dehumidifying Volume |
L/Hr |
3 |
||||
Air Flow Volume (Max) |
L/Sec |
347 |
||||
Sound Pressure (Min/Max) Ind |
dB(A) |
30 ~ 52 |
||||
Sound Power (Min/Max) Ind |
dB(A) |
46 ~ 68 |
||||
Sound Pressure / Power Out |
dB(A) |
61 / 69 |
||||
Electrical |
||||||
Power Supply (Outdoor) |
V/Hz/Ph |
220~240/50/1 |
||||
Recommended Circuit Breaker |
A |
25 |
||||
Nominal Current (cool/heat) |
A |
11 / 11.7 |
||||
Control Wiring |
3 Core plus Earth (4 Cores) |
|||||
Dimensions and Weights |
||||||
Indoor Dimensions (WxHxD) |
mm |
1078 x 333 x 246 |
||||
Indoor Net Weight |
kg |
15 |
||||
Outdoor Dimensions (WxHxD) |
mm |
958 x 660 x 402 |
||||
Outdoor Net Weight |
kg |
45.5 |
||||
Installation |
||||||
Operating Temp Range Cool |
°C |
-15° ~ 52 |
||||
Operating Temp Range Heat |
°C |
-15° ~ 24 |
||||
Refrigerant Type |
R32 |
|||||
Refrigerant Charge |
kg |
1.2 |
||||
Max Pipe Length (pre-charged) |
M |
40 (10) |
||||
Max Height |
M |
25 |
||||
Additional Refrigerant |
g/m |
16 |
||||
Pipe Connection |
mm |
1/4″ ~ 1/2″ |
Note: Above parameters are for reference only. Actual parameters may vary.
