Haier Smart Power AD125HN5FA‐SET 12.5kW Ducted Air Conditioner System High Static 1 Phase

SKU: AD125HN5FA-SET (AD125S2SH5FA / 1U125S2SN5FA / YR-E17A)

12.5 kW Cooling
14.0 kW Heating

$3,099.00

Or own it from $119.19 weekly for 6 months*

Or pay in slices, no interest ever

9.5 x 15.88mm (3/8 x 5/8)> Ducted air conditioning> Haier Air Conditioning> Haier Ducted Air Conditioners> Haier Smart Power Ducted Air Conditioner Systems | High Static> View All Ducted Systems Compare

	Indoor unit			AD125S2SH5FA
	Outdoor unit			1U125S2SN5FA
Capacity	Cooling		kW nom	12.5
			(min~max)	4.0~14.0
	Heating		kW nom	14.0
			(min~max)	4.1~15.0
Power input	Cooling		kW nom	3.89
			(min~max)	0.50~5.30
	Heating		kW nom	3.73
			(min~max)	0.50~5.30
AEER/ACOP			w/w	3.19/3.72
TCSPF (Hot/Average/Cold climate)		Residential		4.254/3.960/4.088
		Commercial		4.546/4.609/4.909
HSPF (Hot/Average/Cold climate)		Residential		3.918/3.486/2.995
		Commercial		3.906/3.525/3.158
Model/Indoor unit				AD125S2SH5FA
Electrical parameters	Power input		Watt	550

Performance data	Air flow		l/s	905/765/625/490
	ESP		Pa	37~210
	Sound pressure level		dB(A)	47/44/42/39
Installation	External dimensions		HxWxD mm	425x1350x490
	Shipping dimensions		HxWxD mm	510x1565x724
	Net/Shipping weight		kg	59/70
	Supply air connection		WxH mm	1045×307
	Return air connection		WxH mm	1163×353
	Drain		mm	Ø25 (OD)
	Water pump		mm	/
	Controller		Standard	/
		Optional	Touch	YR-E17A
		Optional	Timeclock	YR-E16B
			Wireless	RE02 & YR-HRS01
			Wi-Fi	HI-WB101DEI
Model/Outdoor unit				1U125S2SN5FA
Electrical parameters	Power input		Ph/V/Hz	1/220~240/50
	Rated current		Cooling	17.6
			Heating	16.56
	Max amps		Amps	23.2
	Suggested breaker size		Amps	32
Performance data	Air flow		m3/h	4500
	ESP		dB(A)	75
	Sound pressure level		dB(A)	58
Installation	External dimensions		HxWxD mm	965x950x370
	Shipping dimensions		HxWxD mm	1500x1090x480
	Net/Shipping weight		kg	74/85
	Compressor type			Twin rotary
	Refrigerant type			R32
	Refrigerant liquid pipe		mm	9.52 (⅜)
	Refrigerant gas pipe		mm	15.88 (⅝)
	Max pipe length		m	50
	Max drop between I.U.&O.U		m	30
	Refrigerant qty		kg	2.3
	Chargeless length		m	20
	Additional charge		g/m	45
Working temp	Cooling (Min-Max)		°C	-10 to 46
	Heating (Min-Max)		°C	-15 to 24
DRED	Peak smart (DRED) ready			YES

Comfort in all conditions

Control the humidity level inside using the Dry function. By removing excess moisture in the air, you can create a comfortable and healthy environment that feels cooler – all while using less energy than Cool mode.

Control from anywhere

Installing the optional Wi-Fi accessory lets you control your air conditioning from your phone with the SmartHQ™ app, or use voice control with a smart home device.

Efficient and effective

The DC fan motor is more energy efficient than a standard AC motor and it is also highly adjustable. This means you can adjust the static pressure and airflow for optimal performance to suit your layout.

Simple installation

Designed to fit the standard dimensions of Australian homes, the indoor unit easily fits between roof truss spacings of 600mm. Plus, the removable panels make for easy installation and servicing.

Peace of mind

Moisture from the air is collected during normal operation. The High Static Ducted indoor unit includes a second condensate draining tray to collect liquid overflow in case of a blockage, protecting your ceiling from damage.

Central controller

With an optional central controller, you can control individual or connected units from a simple-to-use display. Schedule your air conditioning to turn on to create the perfect environment just before you wake up, or switch off at the end of the workday.

Haier Smart Power AD125HN5FA‐SET 12.5kW Ducted Air Conditioner System High Static 1 Phase – Brochure

Smart Power ducted air conditioning systems

Haier’s Smart Power ducted air conditioning systems provide an effective whole-of-home heating and cooling solution. Also suitable for commercial spaces, the system ismade up of:

an outdoor unit in a suitable location
an indoor unit, often located out of view in the ceiling
flexible ductwork to deliver airflow to multiple rooms through discreet vents
a controller that is used to control the whole air conditioning system.To suit all kinds of installation requirements, we offer three types of indoor unit:• High static ducted• Low profile ducted• Round way cassette.
