LG WS24-SL 7.1kW Smart Series Inverter Split System Air Conditioner
7.1kW Cooling | 7.7kW Heating
LG Smart Series Reverse Cycle Inverter Split System Air Conditioner
Set WS24-SL
Includes Indoor WS24SLN-23 | Outdoor WS24SLU-23
SMART SERIES (REVERSE CYCLE – INVERTER) *
Wireless remote
| Model | WS24SL | ||
| Indoor Unit | WS24SLN | ||
| Outdoor Unit | WS24SLU | ||
|
Rated Capacity
|
Cooling kw | 7.1 | |
| Heating kw | 7.7 | ||
|
Capacity Range
|
Cooling kw min – max | 1 – 8 | |
| Heating kw min – max | 1 – 8.5 | ||
|
Power Input
|
Cooling Rated | 0.17 – 2.75 | |
| Heating Rated | 0.2 – 3.05 | ||
|
Running
Current |
Cooling Rated | 1.20 – 11.60 | |
| Heating Rated | 1.40 – 12.70 | ||
| EER | W/W | 3.3 | |
| AEER | – | 3.3 | |
| COP | W/W | 3.67 | |
| ACOP | – | 3.66 | |
|
Energy Label / Star Ratings
|
Cooling | 4.0,4.0,4.0 | |
| Heating | 3.0,2.5,1.5 | ||
| Power Supply | 1Ph, 220-240V, 50Hz | ||
|
Indoor
|
Air Flow Rate
|
Cooling, Max / H / M / L | 383/283/233/183 |
| Heating, Max / H / M / L | 433/333/283/233 | ||
| Sound Pressure Level | Cooling, Max / H / M / L / SL | – / 46 / 41 / 36 / 27 | |
| Dimensions (W × H × D) | Net | 1060 x 360 x 265 | |
| Weight | Net | 16.6 | |
|
Outdoor
|
Compressor | Twin Rotary | |
| Condenser | Corrosion Protection | Gold | |
|
Sound Pressure Level
|
Cooling, Rated | 49 | |
| Heating, Rated | 52 | ||
| Sound Power Level | 63 | ||
| Dimensions* (W × H × D) Net | 870 x 650 x 330 | ||
| Weight – Net | 45.7 | ||
|
Operation
Range |
Cooling | -10 ~ 48 | |
| Heating | -10 ~ 24 | ||
| Circuit Breaker A | 20 | ||
| Power Supply Guide No | 3 Core + Earth | ||
| Power Supply to Unit – | Outdoor | ||
| Power and Communication Cable – No. x mm2 | 4 x 1 (including Earth) | ||
|
Piping
|
Size
|
Liquid | ø 6.35 (1/4) |
| Gas | ø 12.7 (1/2) | ||
| Connections Method | Indoor / Outdoor | Flared / Flared | |
| Drain Hose Size | O.D, I.D | mm | 20/15 |
|
Between Indoor & Outdoor
|
Piping Length
|
Min ~ Max m | `3-30 |
| Pre-Charge Length m | 7.5 | ||
| Max. Elevation Difference m | 20 | ||
| Piping Connection Heat Insulation | – | Both liquid and gas pipes | |
|
Refrigerant Charge
|
Type – | R32 | |
| Pre Charge g | 1300 | ||
| Additional Charge g/m | 20 | ||
| Control – | Electronic Expansion Valve |
Description
7.1kW Cooling
7.7kW Heating
Wifi Ready | Google Assistant Compatible
Free Shipping Business Address Only NSW, VIC, QLD
