Rinnai HINRP50M 5.0kW Multi Head System Indoor Unit Only | new model
| Multi Indoor Unit – Wall Mounted | HINRP50M | ||
| Power Supply | V-Ph-Hz | 220~240 -1-50 | |
|
Cooling |
Rated Capacity | kW | 5.2 |
| Rated Input Power | W | 30 | |
| Rated Input Current | A | 0.13 | |
|
Heating |
Rated Capacity | kW | 5.1 |
| Rated Input Power | W | 32 | |
| Rated Input Current | A | 0.15 | |
| Airflow (Hi / Med / Lo) | L/s | 334 / 237 /159 | |
| Sound Pressure (Hi / Med / Lo) @1.4m | dB(A) | 45 / 42 / 29 | |
|
Dimensions |
Net (W x D x H) |
mm |
964 x 222 x 325 |
| Gross (W x D x H) | 1045 x 305 x 405 | ||
| Net / Gross Weight | kg | 10.4 / 14.1 | |
| Refrigeration Pipe Size: Liquid / Gas | mm | Φ6.35 / Φ12.7 | |
| Controller | Type | Wireless Remote Control | |
|
Operating Range |
Cooling |
oC |
17 ~ 32 |
| Heating | 0 ~ 30 | ||
Description
5.0 kW Cooling
5.2 kW Heating
Includes Wireless Remote Control | inbuilt WIFI
R32
